    Shovel Loader Weighing Indicator Controller 400Hz Sampling Frequency

    Ask Lasest Price
    Brand Name : Supmeter
    Model Number : BST106-N59[B]
    Certification : CE
    Price : Negotiation
    Payment Terms : T/T, Western Union
    Supply Ability : 200pcs/month
    Delivery Time : 3-30 working days
    • Product Details
    • Company Profile

    Shovel Loader Weighing Indicator Controller 400Hz Sampling Frequency

    Guaranteed Quality TFT Display Shovel Loader Weighing System


    Technical Specifications:

    Display640×480 TFT color display screen for English character display
    Weight Display Range-99,999~+999,999
    System Weighing Range100~12,000kg
    Scale DivisionOptional 1, 2, 5, 10, 20, 50kg
    Display Resolution1/100,000
    Position Sensor Input Interface2 Switch signal Input
    Output VoltageDC12V
    Max. Output Current100mA
    Oil Pressure Sensor Interface2 Switch signal Input
    Excitation Voltage/Max.CurrentDC12V/100mA & DC5V/100mA
    Signal Input RangeOptional 0~20mV, 0~5V[Factory Set Value]
    ∑-△ADC24-bit, 1,000,000 internal code used
    Sampling Frequency400Hz
    Non-linearity0.005%FS
    Digital Communication InterfaceCOM1RS232
    Report Print10000 Loading Records can be saved, queried and printed, and each record can contain 50pcs Single-bucket-loading-weight value
    IP GradeIP65

    Installation of Position Sensor

    Position sensor includes two modules:

    • Proximity Switch Module: Main Mounting Plate with a chute for length adjustment, Sub-mounting Plate with a chute for angle adjustment, Upper Proximity Switch and Lower Proximity Switch [Detecting Distance: 1~8mm].
    • Magnet Module: Thread Pole, Weld-nut, Tight-nut, Nylon Block, Magnet Block.


    1: Lift-arm Seat; 2: Lift-arm; 3: Main Mounting Plate; 4: Sub-mounting Plate; 5: Weld-nut;

    6: Thread Pole; 7: Nylon Block; 8: Fastening Nut for Position Ajustment; 9: Magnet Block; 10: Upper Proximity Switch; 11: Upper Proximity Switch; 12: Fastening Nut for Length Ajustment; 13: Fastening Nut for Angle Ajustment.

    Sensing Distance Adjustment: Adjust the sensing distance between the Magnet Block and the Proximity Switch to 3~5mm.

    Suggestion: Install the position sensor on the lift-arm seat and lift-arm which are at the same side that the weighing indicator installed on.



    Installation of Oil Pressure Sensor

    Operating Principle

    • Wheel Loader Weigher is a dynamic weighing and auto-totalizing equipment installed on wheel loader without changing the original structure of wheel loader.
    • When the lift-arm of wheel loader lifted to a certain height, the position sensor will trigger the weighing process, and the weighing indicator will collect the oil pressure signal from lower and upper oil chambers of arm-lifting oil cylinder. After signal processing and compensating, Single-bucket -loading-weight will be got and totalized to Totalized Loading Weight automatically, and the Deviation Value between Totalized Loading Weight and Setpoint, alarm messages will be displayed. The operator can judge if the present Single-bucket-loading-weight is valid according to the alarm messages, and confirm the loading weight of last bucket according to Negative Deviation Value for avoiding overloading. After Totalized Loading Weight reached setpoint, the operator should stop loading process, save and print Loading Records.

    Application
