    EMC Design Digital Load Cell Indicator Controller With Display Holding

    Ask Lasest Price
    Brand Name : SUPMETER
    Model Number : BST106-M60S[L]
    Certification : CE
    Payment Terms : T/T, Western Union
    Supply Ability : 1000pcs/month
    Delivery Time : 1-9 working days
    • Product Details
    • Company Profile

    EMC Design Digital Load Cell Indicator Controller With Display Holding

    LoadCell Indicator 4-20mA 0-10V analog Output Weight Transmitter Weighing controller

    BST106-M60S[L] Guide Rail Type
    Weighing / Force Measuring Control Module
    Weight/Force Display, Peak Value Detection / Display Holding,
    Auto Weight-checking, Setpoint DO Output, AO/Digit Transmission

    Applications
    Weight/Force Display, Peak Value Detection&Display Holding, Auto Weight-checking, Setpoint DO Output and AO/Digit Transmission.

    Main Features:
    1. Applications: Weight/Force Display, Peak Value Detection&Display Holding, Auto Weight-checking, Setpoint DO Output and AO/Digit Transmission.
    2. EMC design with high anti-jamming capability, suitable for industrial environment.
    3. 32-bit ARM CPU with 48MHz clock & high arithmetic speed.
    4. 6+6 Red LED digital tubes for English character and digit display.
    5. 4-key English keypad for Menu&Shortcut mode operation.
    6. 24-bit High-precision and high-speed ∑-△A/D conversion module with 1/1,000,000 internal resolution and max. sampling frequency 3200Hz.

    Technical Specifications:

    Display
    LED number6+6 Red LED digital tubes for English character and digit display
    Weight Display Range-9,999~+99,999
    Scale CapacitySetting Range 1~99,999
    Scale DivisionOptional 1, 2, 5, 10, 20, 50, 100, 200, 500
    Display Resolution1/50,000
    Decimal Point PositionOptional 0, 0.0, 0.00, 0.000, 0.0000
    Display Refreshing TimeSetting Range 0.01~1.00s
    Keypad
    4-key English keypad for Menu&Shortcut mode operation
    Weighing Signal Interface
    Excitation Voltage/Max. CurrentDC5V/120mA [8-350Ω loadcells]
    Signal Input Range0~12.5mV
    Output Sensitivity of Loadcell1.0~2.5mV/V
    Optional Sampling Frequency3200Hz, 1600Hz, 800Hz, 400Hz, 200Hz, 5Hz
    Switch&Analog Signal Interface
    DI3 Optional&definable normally open switch inputs
    DO3 Optional&definable normally open transistor switch outputs
    AO0~20mA
    VO0~10V
    Digital Communication Interface
    COM1RS232
    COM2Optional RS485
    COM3Optional CANBUS
    ConnectableHost IPC/PLC and LED Remote Display


    User Interface Diagram

    Keypad Operation

    Key NameFunctionDescription
    【■】【MENU】Enter Main Menu / Exit.
    【LOCK】*Key-locking / Key-unlocking.
    【►】【►】

    Cursor shifts right.
    Display the previous interface or option.

    【ZERO】*Manual Zero without Power-down Protection.
    【▲】【▲】

    Display the next interface or option.
    Digit input: +1 ( 0~9 loop).

    【SET】*Setpoint Parameters Setting.
    8【ENT】Enter / Save / Clear Alarm.
    【CLS】*Clear Screen [Clear the display value of Peak Hold Value and Weight-checking Value].


    Installation


    Terminal


    Delivery
