VFD Panel-mounting Material Level Weighing Controller For Hopper Scale And Platform Scale

Technical Specifications

• Power Supply: AC220V±15%, 50/60Hz, Max. 10W.
• Loadcell Excitation Voltage/Current: DC10V/250mA.
• 8 Loadcells[350Ω] connectable.
• Weighing Signal Input Range: 0~25mV.
• 3 Normally Open Switch Inputs [DI].
• 4 Normally Open Relay Outputs [DO]: AC250V/DC24V, 1A.
• 1 Analog Signal Output [AO]: 4~20mA, 0.05%FS.
• COM1: Fixed RS232&RS485. Free to use one of them.
• COM2: Optional RS232/RS485/RS422/Profibus-DP/Ethernet.
• Connect Host IPC, Remote Display, Printer&Wireless Module.
• Outline Size [W×H×D]: 160 × 84 × 188 mm.
• Panel Cut-out Size [W×H]: 151 × 76 mm.
• Operating Temperature: -25℃～+45℃.
• Protection Level of Front Panel: IP65.
• Accuracy Grade: III.
• Verification Accuracy: 0.02%.
• Static Weighing Accuracy: 0.2%~0.5%.

Model Panel-mounting Installation

Keypad Operation

If there is not any keypad operation in one minute and it’s not in the processes of ‘F2 System Calibration’ & ‘F6 Factory Adjustment’, the controller will return to ‘Main Display Interface’ automatically.

Hopper Weighing Mode :

Material M1 Ration Feeding Mode

Material M1~M3 Ration Batching Mode
