Weighing Controller For Belt Weigher For Corrosion-Proof Belt
Weigher Indicator With AC220V
Main Features:
- Suitable for belt weigher.
- EMC design with high anti-jamming capability, suitable for
industrial environment.
- 32-bit ARM CPU with 72MHz & higher arithmetic speed.
- 160×32 dots LCD display screen with yellow-green background for
English display.
- Menu&Shortcut mode operation with key tone.
- High-precision ∑-△A/D conversion technology and broad-range speed
pulse input circuit.
- Max. Connection Quantity: 8 Loadcells (350Ω).
- Auto-locking, Key-locking, Key-unlocking and Digital
Setting&Calibration functions available.
- Auto Zero Tracking, Speed Calibration and Belt Length Calibration
functions available.
- Optional AO [4~20mA] module for Flow signal output (COM1 port will
be occupied).
- 2 Optional communication ports for connecting IPC/PLC, LED Remote
Display, Serial Printer and Wireless Module.
- Corrosion-proof, water-proof, dust-proof and shock-proof shell for
model wall-mounting.
- Weight Records per shift/day/month of a year can be queried and
printed.
- With the multitasking mode, the weighing process will not be
interrupted by parameter setting and the other operations.
Technical Specifications
Power Supply: AC220V±15%, 50/60Hz, Max. 10W.
Loadcell Excitation Voltage/Current: DC10V/250mA.
8 Loadcells[350Ω] connectable.
Weighing Signal Input Range: 0~25mV.
Speed Sensor Excitation Voltage/Current: DC12V/100mA.
Speed Signal Input Range: 0.5~3000Hz.
COM1: Optional RS232/RS485/RS422/Profibus-DP/Ethernet.
COM2: RS232.
Connect Host IPC, Remote Display, Printer&Wireless Module.
Optional 4~20mA Analog Output [AO] Module by COM1.
Outline Size [W×H×D]: 235.5 × 227.5 × 119.5 mm.
Operating Temperature: -25℃～+45℃.
Protection Level: IP65.
Accuracy Grade: 0.5.
FAQ:
1. Sample is Available?
Yes. This product support free sample. As long as you can bear the
freight charge.
2. What detailed information do I need to provide if I want to
place an order?
We need to know the following information: accuracy, Quantity,
special requirements if you have, etc.
3. Do you have any discount?
Yes, if you buy large QTY, please send us a email, we will give you
a big discount.
4. What terms of payment are available?
We accept T/T, L/C, Trade assurance, Secure payment, Western
Union,etc.
5.When will you arrange the production?
We will arrange the production immediately after receiving your
payment.
6. How do you ensure good product quality?
We have a complete quality control system, all of our products are
fully checked by IQC, OQC departments before shipping to our
clients.
7. How long is the warranty period?
The warranty period for our products is 12 (twelve) months.
If the products from SUPMETER are proved to be unable to work
normally due to unartificial reasons, and the problems can't be
solved by customers under the technical support from SUPMETER, then
customers can send the problematic items back to SUPMETER. SUPMETER
is RESPONSIBLE to MEND (or REPLACE when necessary) them FREE OF
CHARGE.
(Note: if after checking, the returned goods are proved to be in
good condition, the trouble is resulted to be caused by improper
operation by customers, SUPMETER is IRRESPONSIBLE to bear the
shipping & other charges related to the returning.)
